BB-232OPDRI-PH - RS-232 Triple (Heavy Duty) Isolated Repeater, DIN Rail

Heavy Industrial RS-232 (DB9 Male / Female) Isolated Repeater

Extends RS-232 data signals
2kV, three-way isolation (input/output/power)
Data rate: 1.2 to 115.2 kbps
Wide operating temperature: -40 to +85 °C
Rugged IP30 metal case (panel or DIN rail mount)
10-48 Vdc input power (power supply required, sold separately)
IEC-61850-3, IEEE-1613, NEMA TS2, FCC, CE, NEMA TS2, 50G Shock, 4G Vibration

Scheda tecnica
